PN | CDK6116CBEV7 | |
Dimension(mm) | 10550*2550*3250 | |
Energy storage system (kWh) | 255.48kWh | |
Seats | 25+1/86 | |
Specification | ||
Main Parameters
| Product Number | CDK6116CBEV7 |
Motor Type | Full Electric | |
LHD/RHD | LHD左 | |
Kerb weight(kg) | 10500 | |
Gross vehicle weight(kg) | 17500 | |
Max Speed （km/h） | ≥69 | |
Color | White | |
Power System
| Battery capacity(kWh) | 255.48kWh |
Mileage（km，40km/h） | 690 | |
Mileage with full load | 250 | |
Battery type | Lithium iron phosphate battery | |
Charging time(H) | 1.5h | |
Drive motor brand / model | Permanent Magnet synchronous motor TZ380XSCD02 | |
Rated/Max power(kW) | 100/250 | |
Rated/Max torque (N.M) |
| |
Drive motor type | Permanent magnet synchronous motor | |
Drive type | Direct drive | |
Chassis
| Chassis Instructure | Integral Body |
Steering system | Integral power assisted steering | |
Brake System | Front and rear disc pressure double circuit control system, energy storage spring brake
| |
Suspension System | Air suspension, front 2 rear 4 | |
Tire | 275/70R22.5 | |
Tire QTY/pcs | 6 | |
Wheelbase(mm) | 6200 | |
Tread (mm) | Front wheel pitch ：2060 Rear wheel base ：2110/1880 | |
Approach & Departure angle (°) | 8.5/12 | |
Body | Frame | Integral body |
Door arrangement | Pneumatic inner swing front and middle passenger door | |
Air conditioner (A/C) | Singles cooling air conditioning cooling capacity to meet the needs of use | |
Audio & video system | Radio+MP3+high quality speakers
| |
Seats material | Plastic seats for buses | |
Paint | Plain paint (within two colors as standard) | |
Interiors |
●Antiskid plastic flooring ●Electronic clock ●Inner rear view mirror ●Front Independent wiper ●Fire extinguisher | |
