Parameter Item

Metric Unit

Imperial Unit

Dimensions

-

-

Max Platform Height

18.3 m

60 ft

Max Working Height*

20.3 m

66 ft 7 in

Max Horizontal Reach

12.2 m

40 ft

Max Horizontal Working Range**

12.8 m

42 ft

Max Up-and-over Height

7.8 m

25 ft 7 in

Overall Length (Stowed)

8.6 m

28 ft 3 in

Overall Width (Stowed)

2.28 m

7 ft 6 in

Overall Height (Stowed)

2.56 m

8 ft 5 in

Wheelbase

2.43 m

8 ft

Ground Clearance

0.25 m

9.8 in

Platform Size (L×W×H)***

1.83 × 0.85 × 1.1 m

6 ft 2 × 9 ft 10 × 3 ft 7 in

Performance

-

-

Platform Rated Load (Restricted/Unrestricted)

250 kg

551 lb

Max Platform Capacity (Persons, Restricted/Unrestricted)

2 persons

2 persons

Travel Speed (Stowed)

0~5 km/h

0~3.1 mph

Travel Speed (Elevated)

0~1.1 km/h

0~0.7 mph

Gradeability***

40%

40%

Turret Rotation (Angle/Continuity)

360° Continuous

360° Continuous

Platform Rotation Angle

160°

160°

Max Allowable Tilt Angle

5°

5°

Turning Radius (Inner/Outer)

3.48 m/6.29 m

11 ft 5 in/20 ft 8 in

Turret Tail Swing

0.2 m

8 in

Max Allowable Side Force

400 N

90 lbf

Max Allowable Wind Speed

12.5 m/s

28 mph

Tire Specification/Type

33×12D16 (Foam-Filled); 33×12-20 (Solid)

33×12D16 (Foam-Filled); 33×12-20 (Solid)

Power

-

-

Drive/Steering

4WD>2WS

4WD>2WS

Engine (Power/RPM/Spec/Brand)***

43 kW/2500 rpm QSF2.8N4G (Cummins)

57.6 hp/2500 rpm QSF2.8N4G (Cummins)

Fuel Tank Capacity

120L

26.4 gal(UK)/31.7 gal(US)

Hydraulic Oil Fill Volume

100L

22.0 gal(UK)/26.4 gal(US)

Hydraulic Tank Capacity

110L

24.2 gal(UK)/29.1 gal(US)

Diesel Pump Pressure

28MPa

4061 psi

Battery Specification (Voltage/Capacity)

12V/220Ah

12V/220Ah

Control Voltage

12 VDC

12 VDC

Standard Configuration

Optional Configuration
